SKU 430-401001-N Categories ,


aFe Control PFADT Series Featherlight single adjustable street/track coilover systems are ride-height adjustable, as well as damping-adjustable for rebound and compression. Their aluminum bodies yield high strength, while still maintaining a lightweight design. An internal floating piston separates oil and gas, allowing for more predictable handling and a consistent feel. Stainless cross shafts utilize mounts and are retained by a 3/4 in. mono ball and snap rings. You’ll have a quick, easy adjustment with the touch rotary knob, which will adjust both compression and rebound in one device. Elevate your driving experience with comfort, precision, and excitement.



aFe Control is proud to release the PFADT Series, Featherlight Adjustable Coilover System for the 1997-2013 C5/C6 Corvette. Designed as a complete solution the Featherlight Coilovers will allow you to remove the transverse leaf springs and OE shocks on your Corvette yielding a true independent suspension which eliminates the “crosstalk” and harsh ride that the OEM suspension is known for. Both ride height and damping are easily adjustable in this design allowing for fine tuning your Corvette’s stance and ride quality. Packed with features, the coilovers are precision CNC machined from 6061-T6 Aluminum hard anodized. The mono-tube construction utilizes a floating piston to separate the oil and nitrogen gas, allowing for predictable handling and a consistent feel. The CIRC (Concentric Integrated Remote Canister) System more than triples the gas volume over a standard coilover resulting in consistent operation over a wide temperature range and throughout the stroke. Integrated into the CIRC head, is the BOA (Ball on Axis) upper mount, which is a completely sealed design allowing full articulation of the Corvettes suspension and offers a durable quiet mounting solution without travel loss as is common in other clevis style mounting systems. The inverted design places the majority of the mass on the sprung side of the chassis allowing the control arms and outboard components to react quicker and easier without the additional weight of the coilover itself. The result is a suspension system that responds faster to changes in the road whether its highway, local roads, or track surfaces. This design also allows the placement of the damping adjuster on the bottom of the shock, allowing for quick easy adjustment. Since the coilovers employ double digressive valve technology, the easy touch rotary knob will adjust both compression and rebound in one device. You will feel 24 distinct settings on the front and rear shocks allowing for settings to accommodate comfortable street, all the way up to track settings. We even offer a specially tuned version for Drag race set ups. Elevate your driving experience with the comfort, precision, and excitement of aFe Control PFADT Series Featherlight Adjustable Coilovers.


  • Note:
  • Some vehicles equipped with “Mag Ride” electronic shock absorbers will require an additional delete kit, order part # 430-401001-N
  • aFe Control Suspension products are engineered and manufactured in our Corona, California manufacturing facility (MADE IN AMERICA!).


  • C5 Corvette (1997 – 2004)
  • C6 Corvette (2005 – 2013)
  • Base
  • Grand Sport
  • Z06
  • ZR1


  • Ride Height Adjustable/Dampening Adjustable for Rebound and Compression
  • Hard Anodized 6061-T6 Aluminum Bodies for Lightweight and Strength
  • Mono-Tube Construction Utilizes an Internal Floating Piston for More Predictable, Consistent Handling
  • BOA (Ball on Axis) Upper Mount System’s Completely Sealed Mono-Ball Design Makes for a Better Ride and Quiet Operation
Brand: AFE Power
Manufacturer’s Part Number: 430-401001-N
Part Type: Coilover Kits
Product Line: aFe Control PFADT Series Featherlight Single-Adjustable STREET/TRACK Coilover Systems
Coilover Kit Position: Front and rear
Shocks Included: Yes
Adjustable Valving: Yes
Internal Design: Monotube
Gas Charged: Yes
Number of Valving Selections: 24
Coilover Springs Included: Yes
Crossmember Included: No
Adjustable Mounting Bracket Included: No
Hardware Included: No
Welding Required: No
Quantity: Sold as a kit.



AFE Power OE replacement filters are warranted against manufacturer defects for as long as you own the vehicle and it is properly maintained using AFE’s filter cleaning kit. AFE’s universal clamp-on air filters and air intake kits are warranted against manufacturer defects for two years. AFE racing filters are warranted against manufacturer defects for one year. All warranties are contingent upon proper installation and maintenance using AFE’s restore kit. All other AFE products, such as their exhaust systems, intake manifolds, and intercoolers, carry a 2-year warranty.
